New energy vehicle BMS assembly wire harness

Model: NT-OBD26018

Minimum order quantity: 1000 pieces

Payment terms: 30% prepayment via T/T, balance due before shipment.

Delivery time: 3-15 days for samples, 2-4 weeks for bulk orders

Ports of origin: Shanghai, Vietnam

Services: OEM/ODM, Customization

Packaging: Customized boxes, labels, and trays

Contact us

PREV：New energy vehicles High-voltage power wire harness NEXT：US-style 7-core trailer wire harness

Description

The BMS harness is the "data highway" of the battery system, and its core functions are divided into four categories:

Cell status acquisition: Collect voltage and temperature data of individual cells to provide basic data for SOC (State of Charge) and SOH (State of Health) estimation.
Communication and command transmission: Enables CAN/LIN communication between BMS and vehicle control unit (VCU), charging system, and motor controller to transmit control commands and fault information.
High-voltage safety monitoring: responsible for high-voltage interlock circuits, insulation detection signal transmission, monitoring the integrity of high-voltage circuits, and preventing the risk of high-voltage leakage.
Actuator control: Transmits relay/contactor drive signals to control the on/off state of the high-voltage circuit, ensuring safety during the charging and discharging process.

Specifications

Product Name	New energy vehicle BMS assembly wire harness
Application	New energy vehicle battery management system
Cable color	According to customer requirements
Cable length	According to customer requirements
Conductor	Cu-ETP1 bare wire or tin-plated, conforming to DIN EN13602 standard.
External insulation material	PP (thin-walled)
Cable sheath	PP/ PVC/TPE/rubber/silicone, etc.
Connector type	Plug housing assembly suitable for 1.0mm- 4.0mm socket contacts, single locking , multi-pin option available.
Main connector spacing	Main connector 20 -pin rectangular shell connector plug, natural color, 0.157" (4.00mm)
Pin connection	According to customer requirements
Inner copper	Tin-plated/bare copper
Quality Certificate	ISO9001, IATF16949, ROHS, UL, SGS, REACH
Performance testing:	100% electrical and power performance testing before shipment

Application

The BMS assembly wire harness for new energy vehicles is a dedicated low-voltage wire harness assembly for the battery management system (BMS) of new energy vehicles. It is the "nerve center" connecting the battery pack, BMS controller, and the vehicle system, and plays a key role in signal acquisition, communication transmission, and safety monitoring.
