US-style 7-core trailer wire harness
Model: NT-OBD26017
Minimum order quantity: 500 pieces
Payment terms: 30% prepayment via T/T, balance due before shipment.
Delivery time: 3-15 days for samples, 2-4 weeks for bulk orders
Ports of origin: Shanghai, Vietnam
Services: OEM/ODM, Customization
Packaging: Customized boxes, labels, and trays
It is the electrical connection between the American standard tractor/pickup truck and the trailer.
Its center is a grounding pin, surrounded by six blade contacts responsible for transmitting signals such as light and power. The outer casing includes a mounting and securing mechanism.
Ear, trailer hitch for US-spec vehicles.
It is responsible for transmitting signals from the trailer's brake lights, turn signals, side marker lights, and reversing lights , and also supplies power to the trailer's taillights and auxiliary equipment.
The version also supports brake control signal transmission, which is a universal electrical interface for US-spec trailers/RVs.
Commonly found in American pickup trucks, SUVs towing RVs, recreational trailers, and cargo trailers, the corrugated tubing of the cable protects the cable from damage caused by dragging and abrasion.
|
Product Name |
American-style 7-core trailer wire harness |
|
Application areas |
American-style pickup trucks and SUVs towing motorhomes, recreational trailers, and cargo trailers, etc. |
|
Cable color |
According to customer requirements |
|
Cable length |
According to customer requirements |
|
conductor |
According to customer requirements |
|
External insulation material |
TPU (Polyvinyl Chloride) (Thin Wall) |
|
Cable sheath |
PE /TPU /XLPE, etc. |
|
Connector type |
American-style 7-pin blade trailer connector |
|
Pin definition connection |
According to customer requirements |
|
Inner copper |
Tin-plated/bare copper |
|
Quality Certificate |
ISO9001, IATF16949, ROHS, UL, SGS, REACH |
|
Performance testing: |
100% terminal inspection & 100% electrical performance testing & 100% FQC & AQL=0.65 |
Commonly found in American pickup trucks, SUVs towing RVs, recreational trailers, and cargo trailers , the corrugated tubing of the cable protects the cable from damage caused by dragging and abrasion.
