Fuel pump systems Waterproof/sealed APEX 2.8 series wire harness

Model: NT-OBD26023

Minimum order quantity: 1000 pieces

Payment terms: 30% prepayment via T/T, balance due before shipment.

Delivery time: 3-15 days for samples, 2-4 weeks for bulk orders

Ports of origin: Shanghai, Vietnam

Services: OEM/ODM, Customization

Packaging: Customized boxes, labels, and trays

Contact us

PREV：Diesel engine fuel injector wire harness NEXT：OBD Type II Integrated Male to Female Connector to Molex 43025 Miniature Connector

Description

Non-destructive extension of the original vehicle interface
- Function: Extends the original vehicle's controller/instrument/ECU interface, making it easier to move the equipment to other locations for installation (such as modifying the controller to be placed in the seat bucket, or extending the instrument wire harness to facilitate the replacement of the handlebars).
- Advantages: No need to cut the original car wires, just plug and play, retain the original car warranty, and avoid the risks of short circuits and poor contact caused by cutting the wires.

Non-destructive functional expansion (most common use)

Function: Without affecting the original vehicle circuit, a separate wire is cut from the original vehicle interface to supply power or obtain signals for the modified equipment.
Typical scenario:

Provides power/signal access to third-party controllers, Bluetooth modules, instrument clusters, GPS trackers, and dashcams;
It draws out brake, throttle, and light signals to achieve coordinated control of the modified parts;
The CAN bus signal is converted in some models to read vehicle data and expand the functions of the instrument panel.

Dedicated adapter for diagnostics/rewriting
- Function: As a non-destructive diagnostic cable for ECUs/controllers, it connects to a computer via an adapter to read fault codes, rewrite programs, and adjust parameters (such as current limiting for electric motorcycle controllers and tuning of automotive ECUs).

Specifications

Product Name	wire harness/ CAN bus/signal line adapter for waterproof sealing in pump-fuel systems
Application	Car
Cable color	According to customer requirements
Cable length	According to customer requirements
conductor	Cu-ETP1 bare wire or tin-plated, conforming to DIN EN13602 standard.
External insulation material	PP, PVC, TPU
Cable sheath	PP/ PVC/TPE/rubber/silicone, etc.
Connector type	AC slow charging interface, OBC high voltage connector
Pin connection	According to customer requirements
Inner copper	Tin-plated/bare copper
Quality Certificate	ISO9001, IATF16949, ROHS, UL, SGS, ROHS, REACH
Performance testing:	100% electrical and power performance testing before shipment

Application

Without affecting the original vehicle circuitry, a separate wire is cut from the original vehicle interface to supply power or obtain signals for the modified equipment.
