All-in-One Debugging Coiled Wire Harness

Model: NT-XH26062

MOQ:1,000 pcs

Payment Terms: 30% deposit by T/T, full balance due prior to shipment

Lead Time: 15–25 days for samples; 3–4 weeks for mass production

Available Loading Ports: Shanghai, Vietnam

Services: OEM/ODM, Customization

Packaging: Custom export cartons, printed labels & export pallets

Contact us
PREV：SMA to MCX RF Coaxial Cable (RG178 Silver-Plated Coax) / BNC to M12 Industrial Waterproof Coaxial Signal Wire HarnessNEXT：DB9 Serial to RJ45 Ethernet Port / 5525 DC Female Cable / Large DIN Male Wire Harness
  • Description

- Micro USB Male Connector Branch

Standard Micro USB2.0 interface with two functions: 5V charging power supply and device data transmission; used to connect to a computer for reading device logs, upgrading firmware, copying business data, while also recharging handheld terminals.

- RJ45 8-Pin Crystal Head Ethernet Port Branch

Fast Ethernet communication interface, mating with LAN switches/routers, enabling device networking, backend data upload, remote parameter configuration, and batch business data sync.

  • Specifications

Product Name

Custom All-in-One Debugging Coiled Wire Harness

Application

Industrial, instruments, etc.

Cable Color

As per customer requirements

Cable Length

As per customer requirements

Conductor

Cu-ETP1 Tinned Copper

Outer Insulation Material

PVC, TPU, TPE OIL

Cable Sheath

TPU/PVC/TPE/Silicone

Connector Type

As per customer requirements

Pin Connection

As per customer requirements

Inner Copper

Cu-ETP1 Tinned Copper

Quality Certificates

ISO9001, IATF16949, ROHS, UL, SGS, REACH

Performance Testing

100% electrical and power performance testing before shipment



  • Application

-   Industrial Handheld Test Terminals

- Workshop equipment inspection instruments and data acquisition handheld devices, with a coiled spring cable for convenient handheld walking inspection, USB debugging, and network port data upload.

-   Retail / Logistics Handheld Scanning POS Machines

- Supermarket and courier handheld terminals, with wired networking for stable order and logistics data upload, and USB charging for continuous battery life.

-   Portable Industrial Control Operation Handles

- Machine tool and AGV cart handheld controllers, with an extendable coiled cable for convenient long-distance operation, network port syncing device operating parameters.

-   Security Portable Debugging Equipment

- Surveillance engineering debugging handheld devices, network port for camera configuration, USB for exporting recording logs.
