60227 IEC 52 (RVV) 300/300V Copper Core Lightweight PVC Insulated PVC Sheathed Flexible Wire
Product Description and Application
Conductor: Multiple strands of oxygen-free copper wire (or tin-plated copper wire) twisted together, low resistivity, high conductivity;
Insulation: Brand new PVC polyvinyl chloride, with good flexibility, easy bending, moisture resistance, mildew resistance, and aging resistance;
Conductor Stranding: Stranding of the core wires effectively improves the cable's toughness, bending flexibility, and tensile strength; Talc powder is added during extrusion to reduce friction between wires, enhance wire flexibility, and make stripping easier;
Number of Cores: 2 or 3 cores
Rated Temperature Resistance: Suitable for use in environments ranging from -25℃ to +70℃;
Rated Voltage: 300/500V;
Packaging Length: 100 meters/roll, 200 meters/roll, packaged according to requirements;
Applicable Scenarios: Suitable for flexible locations such as medium- and light-duty mobile electrical appliances, instruments, household appliances, electronic equipment, and power lighting; also suitable for cable tray installation.
|
Number of cores × Nominal area |
Conductor structure |
Insulation thickness specified value |
Sheath thickness specified value |
Light inside |
Outer diameter |
Maximum conductor resistance at 20℃ |
Minimum conductor resistance at 70℃ |
|
NO×ø(mm2) |
NO/mm |
mm |
mm |
mm |
mm |
Ω/KM |
MΩ/KM |
|
2×0.5 |
16/0.2 |
0.5 |
0.60 |
1.95 |
5.20 |
39.000 |
0.0120 |
|
3×0.5 |
16/0.2 |
0.5 |
0.50 |
1.95 |
5.50 |
39.000 |
0.0120 |
|
2×0.75 |
24/0.2 |
0.5 |
0.50 |
2.15 |
5.60 |
26.000 |
0.0100 |
|
3×0.75 |
24/0.2 |
0.5 |
0.50 |
2.15 |
6.00 |
26.000 |
0.0100 |
