DB9 RS232 Serial Splitter Wire Harness
Model: NT-XH26064
MOQ:1,000 pcs
Payment Terms: 30% deposit by T/T, full balance due prior to shipment
Lead Time: 15–25 days for samples; 3–4 weeks for mass production
Available Loading Ports: Shanghai, Vietnam
Services: OEM/ODM, Customization
Packaging: Custom export cartons, printed labels & export pallets
Input End: 4 Independent DB9 Male Connectors (Device Side)
4 sets of independent DB9 male connectors, each with its own shielded cable, mating respectively with 4 downstream devices (PLCs, inverters, sensors, card readers, industrial control instruments, time-attendance terminals, etc.), with each serial circuit fully independent and free of crosstalk.
Combined Output End: 1 DB9 Female Connector (Host Computer Side)
The four serial signals are combined into a single 9-pin DB9 female connector, plugging directly into the computer's COM port or a USB-to-RS232 adapter, enabling a single computer's serial port to manage 4 devices simultaneously.
Cable Construction
Black multi-strand shielded serial cable, with each branch independently shielded to isolate motor and power supply EMI; connectors are overmolded and reinforced with fixing screws, resistant to loosening or wire breakage under long-term vibration; internally color-coded wires follow the standard RS232 transmit-receive-ground three-wire pin definition.
|
Product Name |
Custom DB9 RS232 Serial Splitter Wire Harness |
|
Application |
Industrial, instruments, etc. |
|
Cable Color |
As per customer requirements |
|
Cable Length |
As per customer requirements |
|
Conductor |
Cu-ETP1 Tinned Copper |
|
Outer Insulation Material |
PVC, TPU, TPE OIL |
|
Cable Sheath |
TPU/PVC/TPE/Silicone |
|
Connector Type |
DB9 Serial Male/Female |
|
Pin Connection |
As per customer requirements |
|
Inner Copper |
Cu-ETP1 Tinned Copper |
|
Quality Certificates |
ISO9001, IATF16949, ROHS, UL, SGS, REACH |
|
Performance Testing |
100% electrical and power performance testing before shipment |
- Automated Production Line Industrial Control Debugging
- Parallel debugging of multiple inverters, servo drives, and PLCs, batch reading and writing of device parameters;
- Instrument and Meter Test Stations
- Multiple temperature, pressure, and flow instruments simultaneously connected to a host computer for data acquisition;
- Access Control / Time-Attendance / POS Equipment Service Debugging
- Centralized debugging and record export for multiple card readers and time-attendance machines in a store;
- Server Room Small Equipment Maintenance
- Centralized Console port debugging for multiple serial switches and serial servers.
